£589.77 (ex VAT)
Megger LRCD210 Combined Loop/RCD Tester
The Megger LRCD210 is the latest generation of combined non-tripping loop tester and RCD test instruments that provide simple, affordable and flexible test tools for electrical contractors testing energised circuits.
This instrument provides three phase safe non-trip loop testing and 1/2I, I, and 5I RCD testing for standard, selective and DC RCDs. Suitable for domestic installers testing to UK Part P requirements.
The Megger LRCD210 is designed using the new Megger electricians tester case, providing tough rubber armouring, built-in front cover, weatherproof to IP54 and easy-to-use functions and layout. The Megger LRCD210 can be hung around the neck or hand held and will not slip if placed on a bench or shelf. Test leads can remain attached with the front cover open or closed. L-N-E connection indicator LEDs show connection status and reverse polarity supplies.
Instrument will not trip RCDs rated at 30 mA or greater during loop testing, even electronic RCDs.
Features:
| Selection Guide | LRCD200 | LRCD210 | LRCD220 |
| Calibration certificate | ■ | ■ | ■ |
| Loop Testing | |||
| Non Tripping Loop Test | ■ | ■ | ■ |
| PFC | ■ | ■ | ■ |
| Single Phase | ■ | ■ | ■ |
| Hi Current Loop Test | ■ | ||
| Phase to Phase | ■ | ||
| 3 Phase Safe | ■ | ||
| Voltmeter | ■ | ||
| RCD Test | |||
| 1/2 x 1 Test | ■ | ■ | |
| 1 x 1 Test | ■ | ■ | ■ |
| 5 x 1 Test | ■ | ■ | |
| Auto RCD | ■ | ||
| Touch/Contact Voltage Display | ■ | ■ | ■ |
| Selectable 25/50 V Touch Voltage | ■ | ■ | ■ |
| 10, 30, 100, 300, 500mA Ranges | ■ | ■ | ■ |
| 1000mA | ■ | ||
| AC, AC Selective, DC & DC Selective RCD tests | ■ | ■ | ■ |
| Selectable phase 0/180 | ■ | ■ | ■ |
| Ramp test (20% to 110%) | ■ | ■ | ■ |
| General Testing | |||
| Frequency | ■ | ■ | ■ |
| Phase rotation | ■ | ||
| Reverse polarity operation (Continental instruments only) | ■ | ■ | ■ |
| Backlight | ■ | ||
| Mechanical | |||
| BS1363, CEE7/7, AS/ NZS 3112 plug variants | ■ | ■ | ■ |
| IP54 | ■ | ■ | ■ |
| Working voltage 230 V | ■ | ■ | |
| Working voltage 110 & 230 V | ■ |
What’s Included
