Testo 550s Smart Digital Manifold
testo 550s – the manifold with Bluetooth and 2-way valve block for commissioning, servicing and maintenance of refrigeration systems and heat pumps. The testo 550s can be used for applications with A2L refrigerant, taking into account the relevant legislation, norms and guidelines for refrigeration systems
The testo 550s digital manifold with 2-way valve block enables you to carry out your measurements on refrigeration and air conditioning systems and heat pumps particularly fast. The large display also helps you to evaluate the results in graphic form. Stored programs guide you through the measurement and enable the automatic determination of numerous important system parameters such as superheat, pressure drop test or evacuation.
Bluetooth probes for temperature, pressure and humidity can be easily connected directly to the instrument and offer maximum flexibility in their application. In conjunction with the testo Smart App, you can take care of digital documentation directly on site. In addition to this, you always have the current refrigerants available to you, and can set your favourites and transfer them to the instrument. Its proven quality and great durability guarantee the continuously high performance of your manifold in all conditions.
Testo 550s key features
- Large display shows everything at once
- Compact and reliable with IP 54 rating
- Wireless measurement of vacuum and temperature via automatic Bluetooth connection
- Guided measurement menus for target superheat, vacuum and pressure loss
- Refrigerant management in the App with favourites and automatic updates
Testo 550S measurement specification
Pressure
- Range: -1 to 60 bar
- Accuracy: ±0.5% fs
- Resolution: 0.01 bar
- Probe connections: 3 x 7/16″ – UNF
- Overload: 65 bar
Temperature
- Range: -50 to +150°C
- Accuracy: ±0.5°C
- Resolution: 0.1 °C
- Probe connections: 2 x plug-in (NTC)
Testo 550 general specifications
- Operating temperature: -20 to +50 °C
- Battery life: up to 250 hours
- Auto power off after 10 minutes
- Dimensions: 210 x 121 x 60mm
- Weight: 826 grams
- IP54 rated
- Bluetooth 5.0 / 150m
The Testo 550s is available in a range of kit options with different accessories. The contents for each testo 550s kit is listed below…
Testo 550s Basic Set:
- testo 550s digital 2-way manifold
- Batteries (4 x AA)
- Calibration protocol
- Clamp temperature probe kit (2 x clamp probes NTC)
- Transport case
- Instruction manuals
Testo 550s Smart Kit
- testo 550s digital 2-way manifold
- Batteries (4 x AA)
- Calibration protocol
- 2 x testo 115i wireless Bluetooth clamp thermometers
- Transport case
- Instruction manuals
Testo 550s Smart Kit with filling hoses
- testo 550s digital 2-way manifold
- Batteries (4 x AA)
- Calibration protocol
- 2 x testo 115i wireless Bluetooth clamp thermometers
- Hose filling set with 3 hoses
- Transport case
- Instruction manuals
