FLIR EV86-T2 EV Charger Analyzer with Meterlink
The FLIR EV86-T2 EV Charger Analyzer with Meterlink is an all-in-one instrument for testing the safety and performance of AC EV charging stations in residential and commercial settings. It supports Level 1 and Level 2 chargers and combines automated test sequences with clear pass or fail results. A built-in Type 2 connector and included Type 2 to Type 1 converter provide connection options for compatible charging equipment.
Technicians can carry out complete EVSE diagnostics using Control Pilot state simulation, CP waveform analysis, RCD performance verification, error simulation and loop impedance measurement. Protective Earth pre-testing checks for hazardous voltage before testing, while pre-test voltage verification supports safer inspection work. Voltage phase indication covers L1, L2, L3, PE and N.
The FLIR EV86-T2 EV Charger Analyzer with Meterlink also supports faster recording and reporting through Bluetooth Low Energy connectivity. Meterlink connectivity enables wireless data transfer to the FLIR Meterlink app for mobile report generation, data management and sharing from a mobile device. A 3.5 in. TFT-LCD, rechargeable lithium battery and stated 12-hour continuous battery life support practical use during testing work.
Key Benefits
- Automated test sequences reduce the number of manual testing steps.
- Protective Earth pre-testing helps verify that hazardous voltage is not present before testing begins.
- Clear pass or fail results make inspection findings easier to review.
- Control Pilot simulation and waveform analysis support detailed EVSE fault finding.
- RCD testing supports both trip-time and ramping-current checks.
- Loop impedance measurement adds another diagnostic check for charger operation.
- Bluetooth Low Energy enables wireless transfer of test data over a stated range of 10 m.
- Meterlink app connectivity supports mobile reporting, data management and sharing.
- Built-in Type 2 connectivity and the included Type 1 converter provide support for both connector types.
- A rechargeable battery with up to 12 hours of continuous stated operation supports extended test sessions.
Common Applications
FLIR EV86-T2 EV Charger Analyzer with Meterlink is suitable for a range of testing, maintenance and inspection tasks, including:
- Safety and performance testing of AC EV charging stations.
- Testing Level 1 and Level 2 EV chargers.
- Residential EV charging station diagnostics.
- Commercial EV charging station diagnostics.
- Control Pilot state simulation and waveform analysis.
- Protective Earth pre-testing before charger inspection.
- RCD trip-time and ramping-current testing.
- Loop impedance measurement during EVSE diagnostics.
- Voltage phase indication for L1, L2, L3, PE and N.
- Wireless report generation and test-data management through Meterlink connectivity.
Why Choose This Model?
The FLIR EV86-T2 EV Charger Analyzer with Meterlink combines automated EVSE testing, Type 2 and Type 1 connection support, Protective Earth pre-testing, RCD checks, loop impedance measurement and Bluetooth Meterlink reporting in one instrument.
