T&R DFK5050 WPC1000 Switchgear Kit
The T&R DFK5050 WPC1000 Switchgear Kit expands the capability of compatible WPC wireless phase comparator systems. It enables high-voltage phase comparison inside switchgear cubicles while removing the need for trailing wires. This helps keep the working area clear and reduces cable interference during testing.
Two capacitive coupled 60-degree bent end adaptors provide access to conductors in confined switchgear spaces. Their angled form helps technicians reach points that may be difficult to approach with a straight probe. Each adaptor is 250 mm long and 15 mm in diameter, allowing stable capacitive coupling during phase comparison work.
Two DDC0245 operating handles give technicians controlled positioning during each test. The 750 mm handles include a 350 mm fixed insulating element measured from the hand guard, which increases the available phasing distance. A black carry bag keeps the T&R DFK5050 WPC1000 Switchgear Kit organised, protected and ready for transport between electrical test locations.
Key Benefits
- Enables high-voltage phase comparison inside switchgear cubicles.
- Removes trailing wires to keep the immediate work area clearer.
- Reduces the risk of trips and cable interference during testing.
- Extends the available phasing distance in confined environments.
- Angled adaptors improve access where straight probes are unsuitable.
- Operating handles support accurate positioning and stable contact.
- Capacitive coupling supports reliable phase comparison measurements.
- Separate components can be stored together in the supplied carry bag.
- Lightweight kit components are easy to position during test work.
Common Applications
T&R DFK5050 WPC1000 Switchgear Kit is suitable for a range of testing, maintenance and inspection tasks, including:
- High-voltage phase comparison within switchgear cubicles.
- Phase comparison using compatible WPC wireless comparator systems.
- Testing conductors positioned inside confined switchgear spaces.
- Accessing conductors that cannot be reached effectively by straight probes.
- Electrical maintenance work requiring increased phasing distance.
- Phase checks where trailing test wires would obstruct the work area.
- Routine electrical test work at different switchgear locations.
Why Choose This Model?
The supplied information does not identify alternative kit models for direct comparison. This model suits users who need a dedicated WPC1000 accessory kit with bent capacitive adaptors, insulated operating handles and no trailing wires during phase comparison.
What’s Included
- 2 x capacitive coupled 60-degree bent end adaptors
- 2 x operating handles
- 1 x black carry bag
