T&R HVD37/2A KIT 66-132kV High Voltage Detector Kit
The T&R HVD37/2A KIT 66-132kV High Voltage Detector Kit helps personnel verify that high-voltage conductors have been safely de-energised before work begins. It operates across a system voltage range of 66 kV to 132 kV and has a 9 kV activation threshold. Clear green and red LED indication, together with a high-intensity buzzer, makes the line status easy to detect.
Designed for practical field use, the detector responds in less than one second and includes a self-test facility for performance checks. Its high-impact ABS body is shock and drop resistant, while the 0.6 kg instrument weight makes handling easier. The T&R HVD37/2A KIT 66-132kV High Voltage Detector Kit is suitable for both indoor and outdoor use and operates from 25°C to +55°C.
A range of supplied connection accessories supports use with different operating poles and applications. The kit includes a Y-shaped contact electrode, Star Wheel Adaptor, Bowthorpe Rod Adaptor and a 40 mm aluminium hook, along with an accessory bag, polymer cleaning kit and instruction manual. An external battery-operated proving unit can also be obtained separately for comprehensive kit verification, while the orange ABS carry case keeps the detector and accessories together for transport between work sites.
Key Benefits
- Helps confirm that high-voltage conductors are de-energised before work starts.
- Provides a response in less than one second for quick status checks.
- Uses bright green and red LEDs for clear visual indication.
- Adds a high-intensity buzzer for easier detection in high background noise.
- Supports pre-use and post-use performance verification through its self-test facility.
- Combines a 0.6 kg weight with a high-impact ABS body for practical field handling.
- Supports indoor and outdoor use across the stated operating temperature range.
- Provides several supplied adaptors and contact accessories for connection to operating poles.
- Allows easy access to the battery for replacement.
- Uses a purpose-designed orange carry case for secure storage and transport.
Common Applications
T&R HVD37/2A KIT 66-132kV High Voltage Detector Kit is suitable for a range of testing, maintenance and inspection tasks, including:
- Verifying de-energisation of high-voltage lines before work begins.
- Checking the status of high-voltage conductors.
- Pre-work voltage detection on 66 kV systems.
- Pre-work voltage detection on 132 kV systems.
- Indoor high-voltage conductor checks.
- Outdoor high-voltage conductor checks.
- Voltage detection using compatible operating poles and supplied adaptors.
- Applications using the supplied 40 mm aluminium hook.
Why Choose This Model?
This model combines a 66 kV to 132 kV system voltage range with a 9 kV activation threshold, rapid response, LED and audible indication, self-test capability and a rugged 0.6 kg ABS body. Its supplied contact accessories and adaptors also provide several connection options for field use.
