Socket & See IRC PRO Insulation and Continuity Tester

Socket & See IRC PRO

The Socket & See IRC PRO stands at the forefront of testing technology with its digital continuity and insulation resistance capabilities. This advanced device facilitates 1,000V testing and offers up to 500 tests on a quartet of AA alkaline batteries. Enhanced test numbers are achievable at 250V and 500V settings. Its expansive backlit display augments readability, whilst the protective rubber overlay ensures resilience in diverse settings. The IRC PRO is notably safeguarded against inadvertent mains connections, averting a frequent and expensive blunder.

Essential features of the IRC PRO include:

• Insulation Testing: Rotate the dial to the desired voltage, press the testing button, and the LCD will display the applied voltage followed by the outcome.
• Continuity Null Testing: To secure heightened accuracy, execute a lead null to incorporate test lead resistance.
• Continuity Testing: Opt for the continuity mode, attach the leads, and activate the test button. Pre-nulling the leads bolsters precision.
• Hands-Free Functionality: In Continuity or Insulation modes, engage the hands-free feature and start the test with a button press. The test persists until you deactivate hands-free mode or switch off the device.
• Buzzer Feature: For swift resistance assessments, employ the buzzer function by adjusting the dial and applying the test leads.

The Socket & See IRC PRO adheres to BS EN 61010, BS EN 61557, and EMC BS EN 61326 standards.

Key Features

• Insulation testing at 250V, 500V, and 1000V.
• Auto-ranging continuity up to 19.99kΩ.
• Buzzer for quick resistance checks.
• Lead nulling up to 5Ω for accuracy.
• Hands-free operation feature.
• Safety indicators including hazardous voltage alert.
• Auto switch-off for battery preservation.
• Durable, dual insulated test leads.
• GS38 prods and clips included.
• Complies with CAT III 500V and CAT IV 300V standards.

What’s Included

• Socket & See IRC PRO
• Socket & See IRC Pro Manual
• Socket & See Two-Wire Test Lead Set
• Magnetic hanging strap
• 4 x AA batteries
