Amprobe ACD-10 PLUS 600A Clamp Meter
The Amprobe ACD-10 PLUS 600A Clamp Meter is engineered for professionals who demand precision in tight measurement environments. With its thin jaws, just 10mm thick, this clamp meter can easily access confined spaces. It can still accommodate conductors up to 26mm in diameter. The meter measures both AC and DC voltage up to 600V. It also handles AC current up to 600A. This makes it an indispensable tool for electricians and technicians.
Beyond its compact design, the ACD-10 PLUS boasts versatile functionalities such as capacitance measurement up to 3000µF and frequency detection using either the jaws or test leads. The auto-ranging feature simplifies the measurement process, while the hold and maximum reading functions provide essential data retention for further analysis. Designed with durability in mind, it features a rubber over-moulded case that offers enhanced protection in rugged environments.
This meter is also equipped with advanced safety features, including overload protection and an auto power-off function to conserve battery life. Whether you’re working in high or low temperatures, the ACD-10 PLUS performs reliably, making it a robust choice for a wide range of electrical applications.
Key Features
- Measures AC and DC voltage up to 600V
- Measures AC current up to 600A
- Thin jaws, only 10mm thick, for accessing tight spaces
- Capacitance measurement up to 3000µF
- Frequency measurement via jaws or test leads
- Auto-ranging for simplified operation
- Hold and Maximum reading functions for data retention
- Accommodates conductors up to 26mm in diameter
- Rubber over-moulded case for enhanced durability
- Auto power-off to conserve battery life
Technical Specifications
| Feature | ACD-10 PLUS |
|---|---|
| Display | 3-3/4 digits 4000 counts LCD display |
| Update Rate | 3 per second nominal |
| Polarity | Automatic |
| Operating Temperature | 0°C to 40°C, < 80% RH up to 31°C |
| Altitude | Operating below 2000m; Indoor use |
| Storage Temperature | -20°C to 60°C, < 80% RH |
| Temperature Coefficient | 0.15 x (specified accuracy)/°C |
| Low Battery Indicator | Below approx. 2.4V |
| Power Supply | 3V coin battery IEC-CR2032 |
| Power Consumption | 2.8 mA typical, 3.3 mA for ACA function |
| Auto Power Off (APO) Timing | Idle for 30 minutes |
| APO Consumption | 5 µA typical |
| Jaw Opening Conductor Diameter | Max 26 mm |
| Special Features | 30ms Max Hold, Data Hold, Relative Zero mode |
