Teledyne FLIR T530 Professional Thermal Imaging Camera
The Teledyne FLIR T530 Professional Thermal Imaging Camera stands out with its extensive measurement range, high resolution, and exceptional thermal sensitivity. Designed for power generation, electrical distribution, and manufacturing sectors, it features a 320 x 240 pixel thermal sensor that captures clear thermal images and videos of temperatures ranging from -20˚C to 650˚C. For those requiring higher temperatures, an optional calibration extends this range up to 1200˚C. Its sensitivity of <30mK reveals minute temperature differences of just 0.03˚C.
A key feature is its auto-rotating optical block, which swivels 180˚, making it easy to capture thermal images and videos from various angles, ideal for inspections in challenging conditions. The 4” touch screen offers a variety of colour palettes, while MSX® image enhancement integrates details from the built-in digital camera for enhanced clarity. Additionally, time-lapse infrared imaging enables capturing intermittent issues over a 24-hour period.
The camera’s 1-4x digital zoom allows for focused inspections of temperature discrepancies. Post-capture, UltraMax® technology further enhances image quality through FLIR Vision Processing™. The laser-assisted autofocus ensures clear images, and the laser distance measurement provides information on the accessibility of faulty components. With METERLiNK® connectivity, data from Bluetooth-enabled FLIR clamps and multimeters can be displayed and saved directly on the camera. Despite its advanced features, the T530 is user-friendly with intuitive menus and responsive touch controls.
Data transfer is streamlined via USB, Bluetooth, or Wi-Fi, which also supports live video streaming. The camera supports both radiometric and non-radiometric IR videos. Its interchangeable AutoCal™ lens system offers flexibility, allowing lens sharing across multiple cameras. The package includes a 24˚ or 42˚ lens, with the option for a combination of these plus a 14˚ lens. A comprehensive range of accessories is provided, and FLIR’s industry-leading 2-10 warranty covers the camera and its accessories.
Key Features
- Extensive temperature range from -20˚C to 650˚C, extendable to 1200˚C
- High-resolution 320 x 240 pixel thermal sensor for clear imaging
- <30mK sensitivity for detecting minute temperature differences
- 180˚ auto-rotating optical block for versatile angle captures
- 4” touch screen with multiple colour palettes and MSX® enhancement
- Time-lapse infrared imaging for capturing intermittent issues
- 1-4x digital zoom for focused temperature inspections
- UltraMax® technology for post-capture image enhancement
- Laser-assisted autofocus for sharp images
- Laser distance measurement for accessibility assessment
- METERLiNK® connectivity with Bluetooth-enabled FLIR tools
- Intuitive operation with voice and text annotations
- USB, Bluetooth, and Wi-Fi for easy data transfer and live streaming
- Interchangeable AutoCal™ lens system for flexible use
- Comprehensive accessories and industry-leading warranty
Technical Specifications
- Thermal sensor resolution: 320 x 240 pixels
- Temperature measurement range: -20˚C to 650˚C (optional up to 1200˚C)
- Thermal sensitivity: <30mK
- Display: 4” touch screen
- Digital zoom: 1-4x
- Image enhancement: MSX® and UltraMax® technology
- Autofocus: Laser-assisted
- Measurement functions: Spot measurement, hot/cold spots, area measurement
- Connectivity: USB, Bluetooth, Wi-Fi, METERLiNK®
- Storage: 8GB SD card included
- Video: Radiometric and non-radiometric IR video recording
- Lens options: 24˚, 42˚, 14˚ (FlexView Dual FOV lens available)
- Weight: Approximately 1.3 kg
- Dimensions: 250 x 100 x 100 m
