Testo 872 Thermal Imaging Camera
The testo 872s thermal imaging camera stands out thanks to its resolution of 320 x 240 pixels, a very high thermal sensitivity, numerous innovative functions, smartphone connection via the testo Thermography App and the best price-performance ratio of its class. In addition to this, it fits comfortably in the hand and convinces with intuitive operation in a modern tile look. For even more meaningful thermal images, the testo 872s also integrates the measurement values of the clamp meter testo 770-3 as well as the thermohygrometer testo 605i via Bluetooth (both available as an option).
- Detecting structural defects and ensuring construction quality
- Easy checking of heating systems and installations
- Investigating moisture damage
- Preventing mould formation with traffic light risk indication
- Pinpoint roof leaks, especially on flat roofs
- Monitoring and checking solar energy systems to ensure maximum efficiency
- Mechanical systems such as motors, bearings, conveyors and general process machinery
Ultimate connectivity
In addition to its wide range of application uses, the Testo 872 can be used with the Testo thermography app, available on both Android and iOS devices. Reports can be created and sent via the app, meaning results can be sent straight to the person who needs them, whether this be an engineer on site or a customer. The 872s can also be operated via the app and the smart device can be used as a second screen.
Hot and cold spot detection
Automatic hot and cold spot recognition helps flag problem areas quickly and easily, removing the need for timely investigations. This camera also allows the user to view large areas in one go, potentially highlighting multiple critical issues in one snapshot.
Integrated digital camera
An integrated digital camera allows comparison between normal visual images and thermal images side by side. This makes interpreting thermal images much easier, and issues can be pinpointed virtually straight away and marked on the visual image for easy identification on site.
Simplifying emissivity
The Testo 872s makes compensating for emissivity as straight forward as possible. Pre-sets for a range of commonly found materials means the 872 takes the guess work out of setting the correct emissivity level. The 872 can also be used with testo e markers. Simply stick the e marker on the surface to be measured and the camera automatically adjusts the emissivity setting. A manual mode is also available if preferred. The addition of a laser marker means h euser can see exactly what they are measuring.
The feature set and simplicity of the Testo 872s make it an excellent value camera. It takes all the features of the Testo 871s plus adds improved IR resolution, thermal sensitivity, wider field of view and laser marker. Pro software is also included for in depth reporting.
| Infrared image output |
| Infrared resolution | 320 x 240 pixels |
| Thermal sensitivity | <0.05 °C (50 mK) |
| Field of view (FOV) | 42° x 30° |
| Minimum focus distance | < 0.5m |
| Geometric resolution (IFOV) | 2.3 mrad |
| Testo Super Resolution (Pixel / IFOV) | 640 x 480 pixels (1.3 mrad) |
| Image refresh rate | 9Hz |
| Focus | Fixed focus |
| Spectral range | 7.5 to 14 μm |
| Visual image output |
| Image size / min. focusing distance | at least 5 MP / 0.5m |
| Image presentation |
| Image display | 8.9 cm (3.5″ TFT, QVGA (320 x 240 pixels) |
| Digital zoom | 2x, 4x |
| Display options | IR image / real image |
| Colour palettes | 10 (iron, rainbow, rainbow HC, cold-hot, blue-red, grey, inverted grey, sepia, Testo, iron HT) |
| Data interfaces |
| WLAN connectivity | Communication with the testo Thermography App wireless modul BT/WLAN
(EU, EFTA, USA, AUS, CDN, TR) |
| USB 2.0 Micro B | Yes |
| Bluetooth | Measurement value transfer from thermohygrometer testo 605i, clamp meter testo 770-3 (optional) |
| Measurement |
| Measuring range | Measuring range 1: -30 to +100 °C
Measuring range 2: 0 to +650°C |
| Accuracy | ±2 °C, ±2 % of measured value |
| Emissivity range | 0.01 to 1 |
| testo ε-Assist | Included |
| Measurement Functions |
| Analysis function | Mean point measurement, hot/cold-spot recognition, Delta T, area measurement (min-max on area) |
| testo ScaleAssist | Included |
| IFOV warner | Included |
| Humidity mode – manual | Included |
Humidity measurement
with humidity measuring instrument | Automatic measurement value transfer of thermohygrometer testo 605i via Bluetooth (instrument must be ordered separately) |
| Solar mode – manual | Input of solar radiation value |
| Electrical mode – manual | Input of current, voltage or power |
Electrical measurement
with clamp meter | Automatic measurement value transfer of clamp meter testo 770-3 via Bluetooth (instrument must be ordered separately) |
| Imager Equipment |
| Digital camera | Included |
| Full screen mode | Included |
| JPEG storage | Included |
| Laser | Laser class 2 |
| Video Streaming | Via USB, via wireless LAN with test Thermography app |
| Standard lens | 42° x 30° |
| Image storage |
| File format | .bmt; .jpg; export option in .bmp; .jpg; .png; .xls; .csv |
| Memory | Internal memory (2.8GB) |
| Power supply |
| Battery type | Li-ion battery can be charged on-site |
| Operating time | 4 hours |
| Charging options | In instrument / in charging station (optional) |
| Mains operation | Yes |
| File format | .bmt; .jpg; export option in .bmp; .jpg; .png; .xls; .csv |
| Ambient conditions |
| Operating temperature range | -15 to +50 °C |
| Storage temperature range | -30 to +60 °C |
| Air humidity | 20 to 80 %RH non-condensing |
| Physical features |
| Weight | 510 g |
| Dimensions (LxWxH) | 219 x 96 x 95 mm |
| Housing | PC – ABS |
| Housing protection class (IEC 60529) | IP54 |
Testo thermal imaging comparison
| | Testo 865s | Testo 868s | Testo 871s | Testo 872s |
| Infrared resolution (pixels) | 160 x 120 | 160 x 120 | 240 x 180 | 320 x 240 |
SuperResolution resolution
(pixels) | 320 x 240 | 320 x 240 | 480 x 360 | 640 x 480 |
| NETD (thermal sensitivity) | 100mK | 100mK | 00mK | 50mK |
| Field of view (FOV) | 31° x 23° | 31° x 23° | 35° x 26° | 42° x 30° |
Geometric
resolution | 3,4 mrad | 3,4 mrad | 2,6 mrad | 2,3 mrad |
| Focus type | Fixed focus | Fixed focus | Fixed focus | Fixed focus |
| Min. focus distance | < 0,5 m | < 0,5 m | < 0,5 m | < 0,5 m |
| Intergrated digital camera | No | Yes | Yes | Yes |
| Laser marker | No | No | No | Yes |
| Measuring range | -20 to +280°C | -30 to +100°C
0 to +650°C | -30 to +100°C
0 to +650°C | -30 to +100°C
0 to +650°C |
