Anton Sprint Pro3 Multifunction Flue Gas Analyser (Choice of Kit)

Anton Sprint Pro3 Bluetooth Multifunction Flue Gas Analyser

The Anton Sprint Pro3 Bluetooth Multifunction Flue Gas Analyser supports professional combustion testing, inspection and maintenance work. It measures carbon monoxide, oxygen, temperature and pressure while also calculating carbon dioxide, the CO/CO2 ratio and combustion efficiency. Engineers can use the full pressure menu for let-by and tightness testing.

Wireless connectivity links the analyser to compatible iOS and Android devices through the Anton Sprint Mobile app. This connection supports efficient data management and reporting while the USB port allows communication with Anton Sprint Pro PC software on Windows. A large colour display and push-button controls provide clear results and straightforward access to each function.

Built for regular field use, the Anton Sprint Pro3 Bluetooth Multifunction Flue Gas Analyser has a sturdy body, double condensate protection and an overrange system for its carbon monoxide sensors. Its click-in, click-out probe arrangement allows probes to be changed quickly, while the quick-to-empty condensate trap and washable particulate filter simplify routine care. A combustible gas sensor, LED search light and supplied gas escape probe also support gas leak detection tasks.

Key Benefits

• Combines flue gas, pressure, temperature and gas leak testing in one instrument.
• Sends results wirelessly to compatible iOS and Android devices for easier data handling.
• Provides a large colour screen and simple push-button controls for clear field operation.
• Uses double condensate protection to reduce the risk of moisture damage.
• Allows quick probe changes through the click-in, click-out probe system.
• Supports let-by and tightness tests through the full pressure menu.
• Uses an LED search light with the combustible gas sensor to aid leak detection.
• Connects to Anton Sprint Pro PC software through USB for Windows-based recording.
• Includes an overrange system to protect the carbon monoxide sensors.
• Provides up to eight hours of continuous battery use.

Common Applications

Anton Sprint Pro3 Multifunction Flue Gas Analyser is suitable for a range of testing, maintenance and inspection tasks, including:

• Flue gas measurement of carbon monoxide, oxygen and carbon dioxide.
• Combustion efficiency and excess air assessment.
• CO/CO2 ratio measurement.
• Flue and ambient temperature measurement.
• Pressure measurement up to ±100 mbar.
• Let-by and tightness testing.
• Combustible gas leak detection.
• CO room safety reporting for BS7967 work.
• CO ambient air monitoring.
• CO sweep testing for BS7967 work.

Why Choose This Model?

The Pro3 provides the core analyser, probes and field accessories without the additional printer, APRV valve or extra temperature probes supplied in Kit A and Kit B. It suits buyers who need the Pro3 measurement functions but do not require the expanded kit accessories.

Product Comparison

General Specifications

Measurement and Accuracy Specifications

Mechanical and General Information

Specification Notes

• The Anton Pro Printer communicates by infrared and is available separately with the standard Pro3 kit.
• The analyser can be upgraded to a higher model at a later date.
• Kit A and Kit B add accessories to the standard Pro3 package without changing the listed Pro3 analyser functions.

What’s Included

• Anton Sprint Pro3 flue gas analyser
• Sprint Pro flue probe with Water Stop technology and washable particulate filter
• Sprint Pro Quick Drop carry bag
• USB charger and lead
• Sprint Pro gas escape probe
• Standard pressure hose
• AS10 clamp pipe temperature probe
• Spare filter
• Quick start guide
• Calibration certificate
