ATP DM-830D Manual Ranging Digital Multimeter
Compact pocket size 3½ digit Multimeters. They are ideal for use by electricians, electronic engineers, general industry and laboratories. A single positive click action rotary selection switch provides ease of use. They offer multi-function measurement capability and 220Vrms overload protection. Note: 10A range is unfused.
Features:
- Impact-resistant ABS plastic case
- 22mm LCD display with large digits and function indicators
- Manual Ranging via single positive click action rotary switch
- Auto Polarity indication
- Fast Blow Fuse for overload protection
Specifications:
| Range Resolution Accuracy |
Voltage AC 200V, 750V 100mV, 1V ±1.2% ±10 digits |
Voltage DC 200mV, 2000mV, 20V, 200V, 1000V 100µV, 1mV, 10mV, 100mV, 1V ±0.5%DCV ±2 digits |
| Range Resolution Accuracy |
Current DC 200µA,2000µA, 20mA, 200mA, 10A 100nA, 1µA, 10µA, 100µA, 10mA ±1.2% ±2 digits |
|
| Range Resolution Accuracy |
Resistance (Ohms) 200, 2000, 20K, 200K, 2000K Ω 100m, 1, 10, 100, 1K Ω ±0.8% ± 2 digits |
|
| Diode Test Continuity |
Max open circuit 2.8V Audible beeper if resistance is less than 100Ω |
|
What’s included?
- ATP DT-830D
- 2 Test Leads
- Battery
