TPI DC710 Flue Gas Analyser

TPI DC710 Flue Gas Analyser

The TPI DC710 Flue Gas Analyser elevates gas diagnostic tools to an unparalleled level. This sleek device offers precise measurements for CO within a 0-10,000ppm range, accurately gauges temperatures from -50˚C up to 1000˚C, and pinpoints oxygen levels up to 25%. Additionally, it’s proficient in assessing vital metrics such as CO2, combustion efficiency, and air-free CO.

Its game-changer? Bluetooth integration. Instead of a conventional screen, users can effortlessly connect to the TPI View app on their smartphones. This not only ensures remote access to readings but also negates the need for extended hoses. Simply place the analyser near the combustion source, and use the phone to both view results and store data.

Crafted for durability, the DC710 boasts a resilient design complete with rear magnets and a hook for steadfast positioning. Beyond its functionality, the device comes with a confidence-inspiring 12-year warranty, setting a benchmark for flue gas analysers in the UK. To maintain this impressive warranty, annual calibration is recommended.

Key Features:

• Operate remotely via Bluetooth using your Smartphone or tablet and the free TPI app.
• No need for long probe hoses – you can be at the control centre with your smartphone, while the DC710 does the work at the stack.
• The free TPI app provides on-site reports which can instantly be emailed and stored without the need for paper or printers.
• 24-Hour real-time clock for accurate documentation.
• Powerful magnetic and/or hook mounting.
• Durable, rugged and sealed housing.
• Will work with any probe that has a large water trap

Flue Gas Analysis:

• Measure CO, and Temperature Differential
• Calculate CO2, CO Air Free, Excess Air, and Combustion Efficiency

Ranges:
Gases

• Oxygen (O2): 0~25%; +/-0.3% accuracy
• Carbon Monoxide (CO): 0~10,000ppm; +/- 5ppm or 5% of reading whichever is greater accuracy

Ranges:
Temperature

• -50°C to 1000°C (-58°F to 1832°F); +/- 0.3% of reading +1°C (+/-0.3% of reading +2°F)

Kit Options

• DC710 Analyser ONLY – A charger is included but no flue probe
• DC710 C1 Kit – Includes A770 flue probe and soft carry case
• DC710 C2 Kit – C1 Kit PLUS TPI SP620 smart probe
• DC710 CPA1 Kit – C2 Kit plus GK11M Temperature Air Probe, A763 Mini In-Line Pump Protection Filter, CPAK3 CPA1 Probe Kit and CK21M Temperture Clamps

What’s Included

• TPI DC710 Flue Gas Analyser
• Charger

Please Note: the DC710 does not come supplied with a calibration certificate.

The unit comes with a certificate of conformity and a calibration verification sticker on the reverse of the instrument.
This is widely accepted by the Gas Safe Register.
